Световая завеса Keyence SL-R12EX Safety Light Curtain, Application Unit — продавец №9837496

Description The Keyence SL-R12EX is an Intelligent Extension Application Unit in the SL-C Series safety light curtain family. It is designed for use with the SL-R11 Intelligent Safety Relay Unit and SL-U2 dedicated power supply unit, and expands the safety functionality of SL-C Series Type 4 safety light curtains. Refer to manufacturer documentation to confirm compatibility with your specific application. The SL-R12EX draws its power directly from the SL-R11 or SL-U2 — it has no independent power supply input. Muting inputs are rated at 24 VDC / 2.3 mA with a maximum input voltage of 26.4 VDC and an ON-threshold of 19 V; bank selection inputs are rated at 24 VDC / 1.6 mA. The unit adds advanced application functions to the connected SL-C system including floating blanking (up to three beam axes), fixed blanking, blanking blind protection, and muting. The housing is constructed from polycarbonate and the unit weighs approximately 300 g. The SL-R12EX must be installed inside a control panel or enclosure rated at minimum IP54 per IEC 60529. It is a dedicated add-on for the SL-C Series and must not be operated independently from that system. Technical Specifications Brand: Keyence MPN: SL-R12EX Type: Safety Relay / Intelligent Extension Application Unit Series: SL-C Function: Muting, Floating Blanking (1–3 axes), Fixed Blanking, Blanking Blind Protection Power Supply: Supplied by SL-R11 or SL-U2 (not independently powered) Muting Input Voltage: 24 VDC / 2.3 mA (max 26.4 VDC) Muting Input ON-Threshold Voltage: 19 V Muting Input OFF-Threshold Current: 0.5 mA Muting Input Common: A common for A1 and A2; B common for B1 and B2 Bank Selection Input Voltage: 24 VDC / 1.6 mA (max 26.4 VDC) Bank Selection Input ON-Threshold Voltage: 19 V Housing Material: Polycarbonate Weight: Approx. 300 g Enclosure Requirement: IP54 or higher (IEC 60529) — must be installed inside control panel Compatible Parent Units: SL-R11, SL-U2 Compatible Light Curtain: SL-C Series (Type 4) Country of Ma
